Tata Winger FL SK 3200 FR 18S

Winger is a multi-utility passenger vehicle that is Bigger on Mileage, Better on Comfort, Best on Earnings.

3200

Wheelbase

74.8kW@3750+/-rpm

Max Power

200Nm@1000to3500rpm

Max Torque

Diesel

Fuel Type

School vans

Application

Overview

The Tata Winger range is built to provide a comfortable and relaxed driving experience, all while maintaining cost-efficiency. It's a versatile multi-utility passenger vehicle that prioritizes fuel economy, passenger comfort, and earnings. The Winger offers a range of passenger-friendly features, making it a top choice for passengers, and its impressive fuel efficiency makes it a preferred option for operators.

Power Of 6

Power of Driver and Passenger Comfort

  • McPherson Strut coil spring with wishbone type suspension
  • Monocoque body structure for car-like comfort
  • Spacious and comfortable seating with deluxe seats and a three-way adjustable seat for the driver

Power of Value

  • TATA Sampoorn Seva 2.0
  • Winger comprehensive AMC
  • Winger Promise 2.0

Power of Style and Design

  • Premium tough design philosophy with new chrome-plated Trust Bar with Tata logo
  • Integrated wraparound DRL with full LED technology-cum-turn signal indicators
  • Split grill with matte black finish and enhanced opening for better airflow and radiator performance

Power of Profit

  • Best-in-class fuel efficiency in vans for higher profits
  • Eco switch gives efficient engine management for higher fuel efficiency
  • Torque based Gear Shift Advisor advises the right time to change gears

Power of Performance

  • Well-proven Tata DICOR 2.2 litre BS6 Phase 2 engine
  • Power output of 74.9 kW at 3750 rpm, offering best-in-class power-to-weight ratio in vans
  • Torque of 200 Nm at 1250-3500 rpm, with peak torque available in a wider interval to reduce gearshifts

Power of Connectivity & Convenience

  • TATA Fleet edge - Fleet Management System
  • Real time vehicle track & trace and Drivers Behaviour Assessment, with Alerts
  • Fuel Consumption & Fuel Theft Monitoring and Vehicle Master and Reminders
MAKE
TATA Motors Limited
MODEL
VARICOR 11
TYPE
Compression Ignition Diesel Engine
NO. OF CYLINDERS
4 Cylinders
DISPLACEMENT
2179
MAX. ENGINE OUTPUT, KW@RPM
74.8kW@3750+/-rpm
MAX. TORQUE, NM@RPM
200Nm@1000to3500rpm
TYPE OF FUEL
Diesel
TYPE
Dry, Single Plate
GEAR BOX TYPE
Synchromesh
NO. OF GEARS
5 Forward + 1 Reverse
TYPE/DESCRIPTION
Rack & PinionType / PowerSteering
TYPE / DESCRIPTION(FRONT)
McPherson Strut with coil spring
TYPE / DESCRIPTION(REAR)
Parabolic leaf spring
SPRING
Front-Coil Spring; Rear-Leaf Spring
ANTI-ROLLBAR(FRONT)
Yes(Optional)
ANTI-ROLLBAR(REAR)
Yes(Optional)
SHOCKABSORBERS(FRONT)
McPherson Strut; 2 Nos
SHOCKABSORBERS(REAR)
Double Acting Hydraulic Telescopic Shock Absorbers; 2 Nos
SERVICEBRAKE(BRIEFDESCRIPTION)
Vacuum Assisted Hydraulic brakes Dual Circuit with Tandem Master Cylinder acting on all four wheels with Automatic wear adjuster at rear.
ABS FITTED (YES/ NO/ OPTIONAL)
Yes
FRONT (DISC / DRUM)
Disc Brake
REAR (DISC / DRUM)
Drum Brake
FRONT
LT 195 R15 8PR
REAR
LT 195 R15 8PR
SYSTEM VOLTAGE, V
12 Volts
BATTERY RATING, AH
80Ah/75Ah/78Ah/65Ah
CAPACITY, LTR
60
WHEEL BASE, MM
3488
OVERALL WIDTH, MM
1905
OVERALL LENGTH, MM
5478
OVERALL HEIGHT, MM
2670
MIN. GROUND CLEARANCE, MM
180mm
SEATING CAPACITY
17+A+D
